Description

Programmable DC Electronic Load.

Max Power: 200W, 100Wx2(Dual), 30W & 250W, 300W, 600W, 1200W

Wide range 0~500V operating voltage

Compatibility between 6310 and 6310A

Up to 8 channels in one mainframe, for testing multiple output SMPS

Parallel load modules up to 1200W for high current and power application

Synchronisation with multiple loads

Flexible CC, CR, CP and CV operation modes

Dynamic loading with speeds up to 20kHz Fast response of 0.32mA/μs~10A/μs slew rate

Minimum input resistance allowing load to sink high current at low voltage

Real time power supply load transient response simulation and output measurement

User programmable 100 sequences Front panel input status for user-friendly operating

High/Low limits of testing parameters to test GO/NG

Digital I/O control

Over current protection (OCP) testing function

16-bit precision voltage and current measurement with dual-range

Remote sensing capability

Short circuit test

Self-test at power-on

Full Protection: OC,OP,OT protection and OV alarm

USB, GPIB & RS-232 interfaces
