Description

Receiver Specifications

• Detection Method & Application: Direct connection method, Coupling method, Induction method
• Depth Accuracy: ±5% (depth below 3m); –15% (depth from 3m to 20m)
• Sound Indication: FM – Sound pitch changes with signal strength
• Function: Pipe detection (cable position tracking, direction display, depth measurement, current measurement), cable identification, tracer probe location, ground fault location
• Power Supply: 7.4V DC 6400mAh rechargeable lithium battery
• Receiving Configuration: Built-in receiving coil; Rogowski coil; A-frame
• Receiving Frequency:
  • Active detection: 128Hz, 512Hz, 577Hz, 640Hz, 1024Hz, 1280Hz, 2.56kHz, 3.20kHz, 4.09kHz, 8.19kHz, 9.50kHz, 9.80kHz, 10kHz, 33kHz, 66kHz, 82kHz, 83.1kHz, 89kHz, 133kHz, 201kHz
  • Passive detection: 50Hz, 60Hz
  • Note: With 512Hz, 640Hz, 1024Hz, 1280Hz, 2.56kHz, 3.20kHz, the receiver can recognize signal direction
• Locating Modes: Broad Peak Mode, Peak Response Mode, Null Mode, Classic Mode, Plan View Mode, Signal Curve Mode, Sonde Position Mode
• Bluetooth: Android App to export Excel files

Interference Distance

• Coupling Method: No interference beyond 5m
• Induction Method: No interference beyond 20m
• Cable identification: No interference beyond 5m when using coupling method

Transmitter (Tx) Specifications

• Power Supply: 11.1V DC 12800mAh rechargeable lithium battery
• Locating Method: Direct Connection, Induction, Signal Coupling
• Output Frequency: 128Hz, 512Hz, 577Hz, 640Hz, 1024Hz, 1280Hz, 2.56kHz, 3.20kHz, 4.09kHz, 8.19kHz, 9.50kHz, 9.80kHz, 10kHz, 33kHz, 66kHz, 82kHz, 83.1kHz, 89kHz, 133kHz, 201kHz
• Output Power: 15W max, 15 power gears, automatic impedance matching
• Output Voltage (Direct Connection): 150V max
• Cable Identification: Rogowski Coil; Calibration Cable 1–10; Successful Identification: 75%–135%
• Detection Range:
  • Direct connection: 0Ω to 8kΩ (up to 20 km cable length)
  • Coupling method: 0Ω to 1kΩ (up to 10 km cable length)
• LCD: 4.3-inch color touch screen
• Receiver Size: 311mm × 133mm × 750mm
• Receiver Weight: 2.0 kg
• Charger: DC 8.4V, 1A
• External Connector: USB (firmware upgrade, phone charging), DC charging port, flexible coil socket
• Rogowski Coil: Length approx. 620mm, diameter 8mm, inner diameter φ200mm
• Working Temperature: –10°C to 40°C; below 80% RH
• Storage Temperature: –10°C to 50°C; ≤95% RH, no condensation
• Dielectric Strength: AC 2000V/rms
• Safety Regulation: IEC61010-1 CAT III 600V, IEC61010-031, IEC61326, Pollution level 2

Additional Specs

• Circuit Protection: Overload and short-circuit protection
• Transmitter Size: 259mm × 211mm × 105mm
• Transmitter Weight: 3.00 kg
• Transmitting Clamp: 1.12 kg, size 250mm × 140mm × 35mm
• Rogowski Coil Diameter: φ150mm
• Test Lead Length: 3m
• Dielectric Strength: AC 3700V/rms
• Safety Standards: IEC61010-1 (CAT III 300V, CAT IV 150V), IEC61326 (EMC)
