NoiseKen Pulse 2b / 4 Generator BP4610
- Description
Description
Pulse 2b : Simulates transients from DC. motors acting as generators after the ignition is switched off.
Pulse 4 : Simulates supply voltage reduction caused by energizing the starter-motor circuits of internal combustion engines, excluding spikes associated with starting.
Features
- Compliant tests to ISO 7637-2 (2011) Standard (Pulse 2b generator)
- Compliant to ISO 7637-2 (2004) Standard pulse 4 generator
- ± 60 V 10 A DC – 150 kHz bipolar amplifier built-in.
- Works as a power source replacing an external battery for testing with the other pulses.
- Expandable to be 15 A or 30 A upon addition of an optional external power supply.
* Requirement of 100 A / 200 A can be responded upon request.
* Optional software shall be necessary for putting Pulse 2b / 4 out.
