Red Phase 689B 3 Phase KWH Meter Tester with Current Source
The Model 689B meter tester uses a Digital Signal Processor and a display processor to measure and calculate meter
errors to 0.03% or 0.1% accuracy.
We are GST registered in New Zealand and we charge in New Zealand Dollars. Foreign-based customers please email us or call our Australian or New Zealand numbers below and we can manually process the sale without New Zealand GST. For Australian customers we can also invoice in AUD and you can pay into our Australian bank account to minimise bank fees and complexities.
Please note that you may be assessed for your countries duties and taxes on import as per your local regulations.
- Description
Description
The Model 689B has a 3 phase switch mode current source.
For testing direct connected meters to 100A there are 6 large
6mm sockets on the front panel. Testing C.T. meters to 10A is
done using the multi pin “CURRENT” socket on the front panel.
Up to 1000 test records can be stored for review or later
downloading to a USB flash drive.
The chassis of the 689B is fitted in a rugged transit case using rubber mounts to protect it against
rough handling in the field. There is a carry handle on top and both ends of the case.
