RigExpert ShackMaster 600
Customers outside of New Zealand, such as Australian and Pacific Islands, to avoid paying NZ GST, please call our Australian or New Zealand numbers and we will arrange the sale.
AUS:+61 2 913 96 981 NZ: +64 9 448 2600
RigExpert’s new cutting edge 600W power supply, the ShackMaster 600 takes shack power to the new level. Compact Desktop 40A|13.8V Power Supply.
Space saving. low noise plus internal protection makes this PSU and ideal option.
Applications:
- Mechanical & electrical equipment sourcing
- Low noise low power amplifiers
- Power sourcing for PoE systems
- Amateur radio
- Lab equipment
- Telecom
- DYI
Main Feature:
- Adjustable output voltage 12-15V, MAX. 40A
- Deadly Quiet
- Lightweight and compact
- DXpeditions compatible
- Tolerant to gasoline generators
- Saves space with flexible orientation
- 4 USB ports with Quick Charge 2.0
Please call for shipping prices as they may vary depending on delivery location.
We are GST registered in New Zealand and we charge in New Zealand Dollars. Foreign-based customers please email us or call our Australian or New Zealand numbers below and we can manually process the sale without New Zealand GST. For Australian customers we can also invoice in AUD and you can pay into our Australian bank account to minimise bank fees and complexities.
Â
Please note that you may be assessed for your countries duties and taxes on import as per your local regulations.
Â
- Description
Description
- Rated power: 600W
- Rated current: 40A
- Output voltage: 13.8V (12-15V Software adjustable)
- Input voltage range: 80V to 264V
- Input frequency range: 47 Hz to 63 Hz
- Acoustic noise: ~21 dB
- Overvoltage protection: Yes
- Overcurrent protection: Yes
- Short circuit protection: Yes
- EMI noise: 200mVp-p
- Storage temperature range: -40°C to +85°C, -40°F to +185°F
- Energy Conversion Efficiency (ECE): > 90% (Heat dissipation at maximum load < 60 W)
- Ports on the front panel: 2 x 3A USB A Charging Ports, 2 x 3A USB Type-C Charging Ports, 2 x 45A Anderson Power Poles
- Ports on the rear panel: 1 x 30A Binding Post, 1 x 45A Anderson Power Pole, 1 x USB Type-C for PC Communication
- Dimensions: 172 mm x 55 mm x 185 mm
- Weight: 1,1 kg
