AEMC Model 6527 Megohmmeter
- Description
Description
Megohmmeter Model 6527
The Model 6527 is a portable multi-range True Megohmmeter® capable of measuring insulation resistance from 1kΩ to 4000MΩ. It has three user selectable test voltages of 250V, 500V and 1000V. The Model 6527 is also a multimeter that features an AC/DC voltmeter function capable of measuring up to 600VAC and 1000VDC, continuity test function with audible beeper for resistances under 35Ω, and an overload protection of 600Vrms. In addition, it can measure resistance up to 400kΩ. The TEST button has an associated locking feature for continuous tests up to 15 minutes, eliminating the need to manually hold down the button. This lightweight, easy-to-use megohmmeter can be used for most commonly performed insulation tests, such as on cables, switch gears, motors, DC generators, power tools and small appliances.
FEATURES
• True Megohmmeter®
• Insulation test voltage selections
of (250, 500, and 1000) V
• Measure insulation to 4000 MΩ (4 GΩ)
• TEST LOCK feature for time sensitive
measurements up to 15 minutes
• Auto discharge after insulation test
• AC/DC voltmeter to 600 Vac/1000 Vdc
• Ohmmeter to 400 kΩ
• Continuity meter with > 200 mA test current
• Test lead resistance compensation for accurate
low resistance measurements
• Auto HOLD function to freeze readings
• Large and bright dual display with blue backlight
• Auto Power OFF feature
• Ergonomic over-molded case with back-stand
