Hioki RM3548-50 RESISTANCE METER
DC resistance meters will measure a broad range of resistance values at a high level of precision. The Hioki RM3548 is a high-precision, portable resistance meter capable of measuring resistance levels from micro-ohms to mega-ohms, and is ideal for the testing and maintenance of large equipment, for example, measuring the winding and weld resistances in large motors and stators for electric and hybrid vehicles.
We are GST registered in New Zealand and we charge in New Zealand Dollars. Foreign-based customers please email us or call our Australian or New Zealand numbers below and we can manually process the sale without New Zealand GST. For Australian customers we can also invoice in AUD and you can pay into our Australian bank account to minimise bank fees and complexities.
Â
Please note that you may be assessed for your countries duties and taxes on import as per your local regulations.
Â
- Description
Description
RESISTANCE METER RM3548-50
High-precision Portable Resistance Meter Measures from µΩ to MΩ
Overview
The RM3548-50 is a precision handheld resistance meter measuring from 0.1 µΩ to 3.5 MΩ. It offers effortless operation and accuracy, making it ideal for EV maintenance, aircraft overhaul, and motor inspections.
Key Features
- 0.02% basic accuracy, 0.1 µΩ max. resolution, 1 A max. testing current
- Measure from 0.1 µΩ (testing current 1 A) to 3.5 MΩ
- Automatic temperature correction ensures accurate results & faster testing
- Advanced Connectivity: seamlessly integrate data with Excel® and a mobile app to manage & analyze data efficiently (*1)
- Protections for safe operation: halts operation & triggers alerts when incorrect voltage inputs are detected
- Versatile Applications: Ideal for EV, aircraft, & motor/transformer maintenance with various probe options
