Pasco • SE-9584 AC/DC Power Supply
SE-9584 Pasco delivers reliable performance with a sleek, modern design—built to meet everyday needs with efficiency and durability. It’s a smart, cost-effective choice that combines quality craftsmanship and dependable results, making it ideal for customers who value performance they can trust.
We are GST registered in New Zealand and we charge in New Zealand Dollars. Foreign-based customers please email us or call our Australian or New Zealand numbers below and we can manually process the sale without New Zealand GST. For Australian customers we can also invoice in AUD and you can pay into our Australian bank account to minimise bank fees and complexities.
Please note that you may be assessed for your countries duties and taxes on import as per your local regulations.
- Description
- Product Specifications
Description
The AC/DC Power Supply has been designed specifically for use in teaching science. It can provide both direct current (DC) and alternating current (AC). The power supply can provide both types of electrical power at the same time, and they can be adjusted independently of one another. Separate digital displays are provided for DC and AC voltage and current outputs.
Features
- Voltage Ranges: 0 to 24 V DC and 0 to 24 V AC
- Maximum DC Current: 10 A up to 12 V DC, 6A up to 24 V DC
- Maximum AC Current: 6A
- Automatic cooling fan
- Use both DC and AC outputs simultaneously
| DC Output Voltage | 0 to 24 V DC |
| DC Voltage Accuracy | 1% ±2 LSD |
| DC Output Current | 0 to 10 A (for 0 to 12 V range); 6 A maximum (for 12 V to 24 V range) |
| DC Current Accuracy | 1% ±2 LSD |
| DC Meters | Digital LED display (volts/amps) |
| AC Output Voltage | 0 to 24 V AC |
| AC Voltage Accuracy | 2% ±2 LSD |
| AC Output Current | 0 to 6 A |
| AC Current Accuracy | 2% ±2 LSD |
| AC Meters | Digital LED display (volts/amps) |
| Overheating Protection | Auto shut-off |
| Power Source | AC 110-120/220-240 VAC, 50/60 Hz |
| Dimensions | 30 x 28 x 13.5 cm (12 x 11 x 5.3 in.) |
| Cooling Fan | Automatically comes on when warm |
| Fuse | T8AL250V P |
| Mass | 3.6 kg |
