Pasco • SE-9586 Kilovolt Power Supply
The SE-9586 Kilovolt Power Supply delivers stable, high-voltage output for demonstrations and laboratory experiments. Designed with safety, reliability, and classroom use in mind, it supports clear investigation of electrostatics and high-voltage phenomena.
We are GST registered in New Zealand and we charge in New Zealand Dollars. Foreign-based customers please email us or call our Australian or New Zealand numbers below and we can manually process the sale without New Zealand GST. For Australian customers we can also invoice in AUD and you can pay into our Australian bank account to minimise bank fees and complexities.
Please note that you may be assessed for your countries duties and taxes on import as per your local regulations.
- Description
- Product Specifications
Description
This Kilovolt Power Supply is used for electron tubes and electrostatics.
The high voltage section is by design “floating” relative to ground. This means that either the black (negative) terminal or the red (positive) terminal may be connected to ground to give a voltage range of 0 to +6 kV, resp. 0 to -6 kV relative to ground.
In addition to the DC kilovolt output, a 6.3 VAC output is provided to power filaments in electron tubes.
The output is well regulated, and the current is limited for safety. The maximum short circuit current is 2 mA. The power supply output shuts off when the maximum current is exceeded and then it automatically resets.
Features
- 0-6 kVDC
- Short-circuit current of 2 mA for safety
- 6.3 VAC filament power source
Applications
- Charge conductive spheres for Coulomb’s Law experiment.
- Use the AC output to power heater filaments in electron tubes.
What’s Included
- 1x Kilovolt Power Supply
- 2x High Voltage Patch Cords
| DC Output Voltage | 0 to 6 kV, continuously adjustable |
| Short Circuit Current | 2 mA (max.) |
| Ripple and Noise (max.) | Less than 1% |
| Accuracy | 1% + 0.01 kV |
| AC Output Voltage | 6.3 V |
| Maximum AC Output Current | 3 A |
| Dimensions | 28 cm (W) x 30 cm (D) x 13.5 cm (H) |
| Power Source | 110-120/220-240 VAC |
| Fuse | F2AL250V |
| Mass | 4.5 kg |
