MECHANICS/ Hooke’s Law and Spring Potential Experiment, EX-5504A
The complete solution for studying the difference between Force and Spring Deformation and investigate both spring compressing and extension.
WHAT’S INCLUDED
- 1x PASPORT Motion Sensor
- 1x IDS Spring Kit
- 1x PASPORT High Resolution Force Sensor
- 1x Force Sensor Track Bracket
- 1x Spring Cart Launcher
- 1x Elastic Bumper
- 1x Braided Physics String
We are GST registered in New Zealand and we charge in New Zealand Dollars. Foreign-based customers please email us or call our Australian or New Zealand numbers below and we can manually process the sale without New Zealand GST. For Australian customers we can also invoice in AUD and you can pay into our Australian bank account to minimise bank fees and complexities.
Please note that you may be assessed for your countries duties and taxes on import as per your local regulations.
- Description
Description
In this experiment, students use a High Resolution Force Sensor to measure the force exerted to either compress or extend various springs, and a Motion Sensor to measure position and speed. Students create a Force vs. Stretch (or Compression) graph. The slope of this graph is known as the spring constant, while the vertical intercept is the initial loading force. Various springs of different construction are included, so students can better understand the physical meaning of the spring constant. The spring is then compressed (or stretched) and released. The kinetic energy transferred to a PAScar is measured and compared to the potential energy lost by the spring.
PASCO Advantage: The High Resolution Force Sensor allows students to take direct measurements of force for each compression or elongation of the spring. This is superior to using a hanging mass to apply a force, since students don’t have to convert from mass to force. In addition, students are applying the forces to the springs and will have a better kinesthetic feel for the amount of force being applied in each case. Energy changes are easily measured and very visual.
Designed for use with any of the following
- 850 Universal Interface
- 550 Universal Interface
- Any PASPORT interface with 2 ports
Concepts
- Relationship between force and spring deformation
- Investigate both spring compression and extension
- Amount of energy stored in a spring
